Elero JA DC

Elero JA DC
  • manufacturer: Elero
  • solar-powered drive
  • control: wired*
  • electromagnetic brake
  • limit position adjustment: manual
  • additional safety switch
  • available torques: 4 Nm and 10 Nm
  • power supply: 12 V DC
  • power: 115–156 W
  • 0.5 m power cable with QuickConnect plug
  • safety rating: IP44
  • speed: 26 rpm
  • maximum continuous operation time: 10 min

Download PDF

The JA DC solar drive for blinds does not require mains power as it operates solely on sunlight. The energy stored in the battery allows it to function after dark and during heavy cloud cover. In the basic version, the drive is controlled via wiring, but with the purchase of the Combio-868 DC receiver, it can also be controlled wirelessly, including in smart home systems.

3 Key Features of JA DC:

Choose the JA DC drive for façade blinds if:

*Wireless control is possible with the Combio-868 DC receiver.




The publication does not constitute a commercial offer. The presented graphic materials are for illustrative purposes only, and the actual colours and textures of the products may differ from those shown in the advertising materials. The graphics presented, including the presentation of colours, cannot constitute the basis for a complaint. Renders show selected profile and glazing sets
